FUTEK IPM500 (D500) Digital Display - Manual (Page 49)

49
Input Types, Ranges, Resolution, Error at 25°C
DC Volts
Range Resol. Resistance Error
200.00 mV
2.0000 V
20.000 V
200.00 V
300.0 V
10 µV
100 µV
1 mV
10 mV
100 mV
1 GΩ
1 GΩ
10 MΩ
10 MΩ
10 MΩ
0.01%
of FS
±2 cts
DC Amps
Range Resol. Resistance Error
2.0000 mA
20.000 mA
200.00 mA
5.000 A
0.1 µA
1 µA
10 µA
1 mA
100 Ω
10 Ω
1 Ω
0.01 Ω
0.01%
of FS
±2 cts
True RMS Volts (0% to 100% of Full Scale,
0 Hz and 10 Hz to 10 kHz, crest factor 3.0)
Range Resol. Resistance Error
200.00 mV
2.0000 V
20.000 V
200.00 V
10 µV
100 µV
1 mV
10 mV
22 MΩ
22 MΩ
1 MΩ
1 MΩ
0.1%
of FS
600.0 V 100 mV 1 MΩ 2V
True RMS Amps (0% to 100% of Full Scale,
0 Hz and 10 Hz to 10 kHz, crest factor 3.0)
Range Resol. Resistance Error
2.0000 mA
20.000 mA
200.00 mA 0.1 µA
1 µA
10 µA
100 Ω
10 Ω
1 Ω
0.1%
of FS
5.000 A 1 mA 0.01 Ω 20 mA
Resistance Measurement
Range Resolution Error
0-20.000Ω
0-200.00Ω
0-2000.0Ω
0-20000 Ω
0-200.00 kΩ
1 mΩ
10 mΩ
100 mΩ
1 Ω
10 Ω
0.01%
of FS
±2 cts
Thermocouple (0.1°, 1° resolution)
Type Range Error
J
-210 to 760°C
-347to 1400°F
.01% FS ±0.09°C
.01% FS ±0.16°F
K
-244 to 1372°C
-408to 2501°F
.01% FS ±0.10°C
.01% FS ±0.17°F
0 to 400°C
-257 to 0°C
.01% FS ±0.03°C
.01% FS ±0.20°C
T
32 to 752°F
-430 to 32°F
.01% FS ±0.05°F
.01% FS ±0.36°F
E
-240 to 1000°C
-400 to 1830°F
.01% FS ±0.18°C
.01% FS ±0.32°F
N
-245 to 1300°C
-410 to 2370°F
.01% FS ±0.10°C
.01% FS ±0.17°F
S
-46 to +68°C
-51 to +213°F
.01% FS ±0.12°C
.01% FS ±0.22°F
R
-45 to 1768°C
-49 to 3214°F
.01% FS ±0.17°C
.01% FS ±0.31°F
RTD
(0.01°, 0.1°, 1° resolution)
Type Range Error
Pt 100Ω
.00385
-202 to 850°C
-331 to 1562°F
.01% FS ±0.03°C
.01% FS ±0.05°F
Pt 100Ω
.003925 -202 to 631°C
-331 to 1168°F
.01% FS ±0.04°C
.01% FS ±0.07°F
Ni 120Ω
.00672
-80 to 260°C
-112 to 500°F
.01% FS ±0.05°C
.01% FS ±0.09°F
Cu 10Ω
.00427
-97 to 260°C
-143 to 500°F
.01% FS ±0.05°C
.01% FS ±0.09°F
Ratio, Potentiometer Follower, Strain
Range Resol. Resistance Error
200.00 mV
2.0000 V
20.000 V 10 µV
100 µV
1 mV
1 GΩ
1 GΩ
1 MΩ
0.01%
of FS
±2 cts
