KEYSTROKES FOR SETUP
If the MENU
key does not work, see Section 9 “Enabling & Locking Out Menu Items.”
Press Menu
Select Key Press Digit
Select Key Press Value Select
Key
_ Strn
Strain or ratiometric
_ 20.0 _ _ __ 50.0 _ _ 100.0 _ 250.0 _ 500.0
20, 50, 100, 250, 500 mV FS voltage
_ InPut
Selection of signal
input type & range
_ dC U U
DC millivolts
_ 20.0 _ _ __ 50.0 _ _ 100.0 _ 250.0 _ 500.0
20, 50, 100, 250, 500 mV FS voltage
0
0_00
Display type
0
4-1/2 digit meter, counts by 1
1 5-digit remote display (±99,999)
2
4-1/2 digit meter, counts by 10
3 3-1/2 digit meter
00 _00
Power line frequency
0 Noise minimized for 60 Hz
1
Noise minimized for 50 Hz
00_ 00
Scaling method
0 Scale and offset method
1
Coordinates of 2 points method
2 Reading coordinates of 2 points method
SEtuP
Meter Setup
00_00
Rear connector control
inputs 1 & 2.
True
= logic 1 (0V or
tied to digital ground)
False
= logic 0 (5V or
open)
0
1 = Reset, 2 = Meter Hold
1 1 = Function Reset 2 = Pk or Valley Disp.
2
1 = Meter Hold 2 = Pk or Valley Disp.
3 1 = Meter Hold 2 = Tare
4
1 = Peak or Valley 2 = Tare
5 1 = Tare 2 = Reset
6
1 = 0, 2 = 0, decimal point 1= XXXXX
1 = 1, 2 = 0, decimal point 1 = XXXX . X
1 = 0, 2 = 1, decimal point 1 = XXX . XX
1 = 1, 2 = 1, decimal point 1 = XX . XXX
7 1 = 0, 2 = 0, decimal point 2 = XXXX . X
1 = 1, 2 = 0, decimal point 2 = XXX . XX
1 = 0, 2 = 1, decimal point 2 = XX . XXX
1 = 1, 2 = 1, decimal point 2 = X . XXX.X
8
1 = Function Reset 2 = Display Blank
9 1 = Hold 2 = Display Blank
A
1 = Peak or Valley 2 = Display Blank
B 1 = Tare 2 = Display Blank
C
1 = Valley Display 2 = Peak Display
D
1 = Tare 2 = Tare Reset
Both control inputs 1 & 1 set to 1 for selec-
tions
2 , 4 , A , C = Function Reset.
Both control inputs 1 & 2 set to 1 for selec-
tions
0 , 1 , 3 , 5 , 8 , 9 , B , D = Meter Reset.
