Option board dependent menu items
ALSEt
.
ALS34 dEU1H dEU2H dEU1b dEU2b dEU3H DEU4H DEU3b DEU4b
Menu items related to alarm setup These will only appear if a relay board is detected. If so,
please see Section16.
AnSEt
.
An Lo
.
An Hi
..
Menu items related to analog output setup. These will only appear if an analog output
board is detected. If so, see Section 17.
SEr 1
.
SEr 2
.
SEr 3
.
SEr 4
. _
Addr
Menu items related to serial communications. These will only appear if an RS232 or
RS485 I/O board is detected. If so, see Section 18.
Gain correction
-Gain
.
Gain correction for negative
signals. Keep at 00.000% to
make positive and negative
gains equal.
0
.0000 0.0000 0.0000
0.0000 0.0000
Gain correction from -29.999%
to +29.9999% of positive gain
for negative inputs.
Select
-2
thru
+2
for flashing
most significant digit. Select
0
thru
9
for other flashing
digits.
Menu lockout items
Loc 1
.
Loc 2
.
Loc 3
.
Menu items used to enable or lock out (hide) other menu items. Loc menu items may in turn
be locked out by a hardware jumper. Please see Section 9.
