FUTEK IPM500 (D500) Digital Display - Manual (Page 34)

34
KEYSTROKES FOR SETUP
If the MENU key does not work, see Section 9 “Enabling & Locking Out Menu Items.”
Press Menu
Select Key Press Digit
Select Key Press Value Select
Key
_- rtd _
RTD
.. d °F - Pt100 RTD, DIN alpha .00385, °F
.. d °C .
Pt100 RTD, DIN alpha .00385, °C
.. A °F -
Pt100 RTD, ANSI alpha .003902, °F
.. A °C - Pt100 RTD, ANSI alpha .003902, °C
. ni °F - Ni120 RTD, alpha .00672, °F
.
.
ni °C - Ni120 RTD, alpha .00672, °C
. Cu °F
-
Cu10 RTD, alpha .00427, °F
. Cu °C
-
Cu10 RTD, alpha .00427, °C
.
Short . Press to store selection for 2-
wire lead resistance compensation. While
holding press
to reset the meter. Short
the two leads at the RTD. Press to store
the displayed value. Then return to _
InPut
to make one of the RTD selections above.
_ InPut
Selection of signal
input type & range
OHnnS
Ohmmeter
.. 20 - 0 to 20 ohms
.. 200 .
0 to 200 ohms
.. 2000 -
0 to 2000 ohms
. 20000 0 to 20000 ohms
200.00 0 to 200.00 kohm
.
Short . 2-wire lead resistance compensation
as for RTD.
0
0_00
Display selection with
scale factor of 1.
0
0.1° RTD or 4-1/2 digits for ohms
1 5-digit remote display (±99,999)
2
0.01° RTD, 4-1/2 digit ohms count by 10
3 1° RTD or 3-1/2 digits for ohms
00 _00
Power line frequency
0
Noise minimized for 60 Hz
1 Noise minimized for 50 Hz
00_ 00
Scaling method
0 Scale and offset method (RTD & ohms)
1
Coordinates of 2 points (ohms)
2 Reading coordinates of 2 points (ohms)
SEtuP
Meter Setup
00_00
Control inputs 1 & 2:
True
= logic 1 (0V or
tied to digital ground)
False
= logic 0 (5V or
open)
0
1 = Reset, 2 = Meter Hold
1 1 = Function Reset, 2 = Peak or Valley
2
1 = Hold, 2 = Peak or Valley Display
3 1 = Hold, 2 = Tare
4
1 = Peak or Valley Display, 2 = Tare
5 1 = Tare, 2 = Reset
