Page 92: Mechanical data
EasiCool™EZE
Precision Air Conditioning
92
EasiCool™ EZE Technical Manual 7588163 V1.1.0_02_2013
Te
ch
ni
ca
l
X-
Ty
pe
V
V35X-EZE-0
V35X2-EZE-0
Standard Matched Condenser
CS50
CS50
Capacity
(1)
Nom Cooling (Gross)
kW
37.1
36.4
Capacity Steps
1
2
Fan Input Power (Fan Gain)
(2)
kW
4.60
4.60
Dimensions - W x D x H
mm
1835 x 750 x 1940
1835 x 750 x 1940
Weight
(3)
kg
498
516
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling / Dehum Stages
1/1
2/2
Fan & Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt & Pulley
Quantity
1
1
Motor Shaft Power
(4)
kW
4.0
4.0
Maximum ESP
Pa
35
35
Nominal Airflow
m³/s
3.3
3.3
Compressor - Scroll
Single
Tandem
Quantity
1
2
Oil Charge Volume (Total)
l
3.25
3.2
Oil Type
Refrigeration
(5)
Single Circuit
Refrigeration Control
Thermostatic Expansion Valve (Optional EEV)
Refrigeration Type
R407C
Holding Charge
Inert Gas
Connections
Liquid (Sweat)
in
5/8
5/8
Discharge (Sweat)
in
7/8
7/8
Condensate Drain Hose
mm
19
19
Filtration
Disposable to BS EN 779 - G4 - 75mm
Quantity
4
4
OPTIONAL EXTRAS
Upgraded Condenser Match
CS65
CS65
Nom Cooling (Gross)
kW
38.2
37.3
Electric Heating (Total)
kW
30
30
Humidifier
Capacity
kg/hr
3.0 - 15.0
3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
5
5
Flow
l/m
10.8
10.8
Drain
10mm Stainless Steel Stub Connection
Larger / Next Larger Fan Motor Size
Quantity
kW
1
1
Motor Shaft Power
(4)
kW
5.5
5.5
Maximum ESP
Pa
240
240
Low Pressure Hot Water
(7)
Copper Tube/Aluminium Fin
Capacity Gross
kW
29.9
29.9
Water Flow (Nominal)
l/s
0.67
0.67
LPHW Connection Sizes
mm
22
22
V35X - V35X2
Technical Data Upflow Units X Type
Mechanical Data
