EasiCool™EZE
Precision Air Conditioning
DF13X - DF17X
64
EasiCool™ EZE Technical Manual 7588163 V1.1.0_02_2013
Te
ch
ni
ca
l
X-
Ty
pe
DF
Technical Data Downflow Units X Type
Mechanical Data
DF13X-EZE-0
DF15X-EZE-0
DF17X-EZE-0
Standard Matched Condenser
C20
C25
C35
Capacity
(1)
Nom Cooling (Gross)
kW
13.2
15.7
19
Capacity Steps
1
1
1
Fan Input Power (Fan Gain)
(2)
kW
0.56
0.92
0.92
Dimensions - W x D x H
mm
990 x 670 x 1940
990 x 670 x 1940
990 x 670 x 1940
Weight
(3)
kg
217
239
242
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling / Dehum Stages
1/1
1/1
1/1
Fan & Motor
Centrifugal Forward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
1
Motor Shaft Power
(4)
kW
0.56
0.92
0.92
Maximum ESP
Pa
282
380
165
Nominal Airflow
m³/s
1.00
1.20
1.40
Compressor - Scroll
Single
Quantity
1
1
1
Oil Charge Volume (Total)
l
1.36
1.85
1.65
Oil Type
Polyol Ester
Refrigeration
(5)
Single Circuit
Refrigeration Control
Thermostatic Expansion Valve (Optional EEV)
Refrigeration Type
R407C
Holding Charge
Inert Gas
Connections
Liquid (Sweat)
in
1/2
1/2
1/2
Discharge (Sweat)
in
3/4
3/4
3/4
Condensate Drain Hose
mm
19
19
19
Filtration
Disposable to BS EN 779 - G4 - 50mm
Quantity
2
2
2
OPTIONAL EXTRAS
Upgraded Condenser Match
C25
C35
C45
Nom Cooling (Gross)
kW
13.3
16.2
19.2
Electric Heating (Total)
kW
7.5
7.5
7.5
Humidifier
Capacity
kg/hr
0.6 - 3.0
0.6 - 3.0
0.6 - 3.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
8
8
8
Flow
l/m
5
5
5
Drain
10mm Stainless Steel Stub Connection
Low Pressure Hot Water
(7)
Copper Tube / Aluminium Fin
Capacity Gross
kW
11.5
12.5
13.3
Water Flow (Nominal)
l/s
0.26
0.28
0.3
LPHW Connection Sizes
mm
22
22
22
