EasiCool™EZE Precision Air Conditioning
90 EasiCool™ EZE Technical Manual 7588163 V1.1.0_02_2013
Te
ch
ni
ca
l
X-
Ty
pe
V
V31X - V31X2 Technical Data Upflow Units X Type
Mechanical Data
V31X-EZE-0 V31X2-EZE-0
Standard Matched Condenser C45 C45
Capacity (1)
Nom Cooling (Gross) kW 31.1 33.2
Capacity Steps 1 2
Fan Input Power (Fan Gain) (2) kW 4.60 4.60
Dimensions - W x D x H mm 1460 x 750 x 1940 1460 x 750 x 1940
Weight (3) kg 452 445
Construction Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour Frame: Aluminium Frame with Aluminium Corners
Evaporator Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling / Dehum Stages 1/1 2/2
Fan & Motor Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type Belt & Pulley
Quantity 1 1
Motor Shaft Power (4) kW 4 4
Maximum ESP Pa 35 35
Nominal Airflow m³/s 2.8 2.8
Compressor - Scroll Single Tandem
Quantity 1 2
Oil Charge Volume (Total) l 4.1 3.2
Oil Type Polyol Ester
Refrigeration (5) Single Circuit
Refrigeration Control Thermostatic Expansion Valve (Optional EEV)
Refrigeration Type R407C
Holding Charge Inert Gas
Connections
Liquid (Sweat)
in 5/8 5/8
Discharge (Sweat) in 7/8 7/8
Condensate Drain Hose mm 19 19
Filtration Disposable to BS EN 779 - G4 - 75mm
Quantity 3 3
OPTIONAL EXTRAS
Upgraded Condenser Match
CS50 CS50
Nom Cooling (Gross) kW 31.7 34
Electric Heating (Total) kW 22.5 22.5
Humidifier
Capacity
kg/hr 1.6 - 8.0 1.6 - 8.0
Feed/Drain 3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m 5 5
Flow l/m 10.8 10.8
Drain 10mm Stainless Steel Stub Connection
Larger / Next Larger Fan Motor Size
Quantity
kW N/A N/A
Motor Shaft Power (4) kW N/A N/A
Maximum ESP Pa N/A N/A
Low Pressure Hot Water (7) Copper Tube/Aluminium Fin
Capacity Gross kW 23.2 23.2
Water Flow (Nominal) l/s 0.52 0.52
LPHW Connection Sizes mm 22 22
