Page 101: Performance data, Operating limits
EasiCool™EZE
Precision Air Conditioning
TC = Total Cooling
SC = Sensible Cooling
THR = Total Heat Rejection
(1) All data quoted is gross
(2) Interpolate for water temperatures between those quoted, do not extrapolate
(3) Water flow rate (l/s) = THR/(4.19*ΔT) at 100% Water; for glycol use refer to Ethylene Glycol Correction Factors section
Technical Data Downflow Units WX Type
Performance Data
Indoor Air Temperature
+18°C to +28°C
Indoor RH%
+40% to +55%
Condenser Minimum Entering Temperature °C
+25°C
Condenser Maximum Leaving Water Temperature °C
+45°C
Operating Limits
Cooling Capacity (1)
Condenser Entering/Leaving Temperature - Based on 5°C ΔT
Air On
25°C/30°C
30°C/35°C
35°C/40°C
40°C/45°C
(DB°C/%RH) TC (kW) SC (kW)
THR
(kW)
TC (kW) SC (kW)
THR
(kW)
TC (kW) SC (kW)
THR
(kW)
TC (kW) SC (kW)
THR
(kW)
DF28WX-EZE
22/50
29
26.9
32
28
26.4
32.6
26.9
25.8
33.2
25.7
25.1
33.9
24/45
29.8
29.2
32.9
28.8
28.6
33.4
27.7
27.7
34
26.5
26.5
34.6
26/40
29.7
29.7
32.8
28.6
28.6
33.6
27.5
27.5
34.3
26.6
26.6
35.1
DF31WX-EZE
22/50
32.6
30.8
35.8
31.5
30.2
36.7
30.3
29.5
37.6
29
28.8
38.5
24/45
33.6
33.3
36.8
32.5
32.5
37.7
31.3
31.3
38.6
30
30
39.4
26/40
34.2
34.2
37.5
33.1
33.1
38.4
31.9
31.9
39.2
30.6
30.6
40.2
DF35WX-EZE
22/50
38.9
36.5
42.5
37.5
35.7
43.6
36
34.9
44.7
34.4
34
45.8
24/45
40
39.6
43.7
38.6
38.6
44.8
37.1
37.1
45.9
35.5
35.5
47
26/40
40.9
40.9
44.6
39.5
39.5
45.7
38
38
46.7
36.3
36.3
47.8
DF40WX-EZE
22/50
42.7
40.6
46.8
41.1
39.8
48
39.6
38.9
49.4
38.1
38.1
50.7
24/45
44.4
44.4
48.4
43.1
43.1
49.8
41.6
41.6
51.2
40
40
52.7
26/40
45.4
45.4
49.4
44.1
44.1
50.8
42.7
42.7
52.3
41.1
41.1
53.8
DF45WX-EZE
22/50
48.1
43.4
51.8
46.5
42.6
53.4
44.9
41.7
55
43.1
40.7
56.7
24/45
49.4
46.9
53.2
47.8
46.1
54.7
46.1
45.2
56.4
44.3
44.2
57.9
26/40
50.4
50.4
54.3
48.9
48.9
55.8
47.1
47.1
57.4
45.3
45.3
59
DF50WX2-EZE
22/50
55.7
49.7
60
54
48.8
61.9
52
47.7
63.9
50
46.6
65.8
24/45
56
53.6
60.5
54
52.5
62.3
51.9
51.3
64.2
50
50
66
26/40
58.4
57.8
62.8
56.6
56.6
64.7
54.6
54.6
66.6
52.6
52.6
68.5
DF55WX2-EZE
22/50
61.6
53
66.4
59.6
51.9
68.4
57.3
50.7
70.5
54.9
49.4
72.6
24/45
63.3
57
68.2
61.2
55.9
70.1
58.9
54.7
72.2
56.5
53.5
74.2
26/40
64.8
61.3
69.7
62.6
60.2
71.6
60.2
59
73.6
57.8
57.8
75.6
DF60WX2-EZE
22/50
65.5
56.9
70.6
63.3
55.7
72.7
60.8
54.4
74.9
58.3
53
77.1
24/45
67.1
61.3
72.3
64.9
60.1
74.4
62.4
58.8
76.6
59.9
57.5
78.7
26/40
69.8
66.8
75.2
67.8
65.8
77.7
65.7
64.7
80.2
63.6
63.6
82.8
101
