EasiCool™EZE Precision Air Conditioning
49 EasiCool™ EZE Technical Manual 7588163 V1.1.0_02_2013
Ins
ta
lla
tio
n
Refrigerant Pipesizing Guide - X Type Downflow
Pipe lengths calculated for Indoor unit with Airedale Outdoor Unit match.
(1) For interconnecting pipework with a predominantly horizontal layout.
(2) For interconnecting pipework with a predominantly vertical layout.
IMPORTANT Tandem Compressor and suction throttle valve applications: In part load, gas velocity should be taken into account
when selecting and commissioning pipework to ensure full oil return.
IMPORTANT REMEMBER excessive pressure loss in interconnecting pipework will impair system performance; this should be
factored in during the design of the system and where necessary oil separators employed.
Indoor Outdoor
Indoor Unit Equivalent Pipe Lengths with R407C
Connection Size 0-15m 15-40m
Liquid Discharge Liquid
Discharge
Liquid
Discharge
Horizontal(1) Vertical(2) Horizontal(1) Vertical(2)
DF6X C11 3/8” 5/8” 3/8” 5/8” 5/8” 1/2” 3/4” 3/4”
DF8X C15 3/8” 5/8” 3/8” 5/8” 5/8” 1/2” 3/4” 3/4”
DF10X C15 3/8” 5/8” 3/8” 5/8” 5/8” 1/2” 3/4” 3/4”
DF13X C20 1/2” 3/4” 1/2” 3/4” 3/4” 5/8” 7/8” 7/8”
DF15X C25 1/2” 3/4” 1/2” 3/4” 3/4” 5/8” 7/8” 7/8”
DF17X C35 1/2” 3/4” 1/2” 3/4” 3/4” 5/8” 7/8” 7/8”
DF22X2 C45 5/8” 7/8” 5/8” 7/8” 7/8” 5/8” 7/8” 7/8”
DF25X2 C45 5/8” 7/8” 5/8” 7/8” 7/8” 5/8” 1 1/8” 7/8”
DF26X C45 5/8” 7/8” 5/8” 1 1/8” 1 1/8” 3/4” 1 1/8” 1 1/8”
DF28X C45 5/8” 7/8” 5/8” 1 1/8” 1 1/8” 3/4” 1 1/8” 1 1/8”
DF31X C45 5/8” 7/8” 5/8” 1 1/8” 1 1/8” 3/4” 1 1/8” 1 1/8”
DF35X CS50 5/8” 7/8” 5/8” 1 1/8” 1 1/8” 3/4” 1 3/8” 1 1/8”
DF40X CS50 7/8” 1 1/8” 7/8” 1 3/8” 1 3/8” 3/4” 1 3/8” 1 3/8”
DF45X CS50 7/8” 1 1/8” 7/8” 1 3/8” 1 3/8” 7/8” 1 3/8” 1 3/8”
DF50X2 CS65 7/8” 1 3/8” 7/8” 1 3/8” 1 3/8” 7/8” 1 5/8” 1 3/8”
DF55X2 CS80 7/8” 1 3/8” 7/8” 1 5/8” 1 3/8” 7/8” 1 5/8” 1 5/8”
DF60X2 CS80 7/8” 1 3/8” 7/8” 1 5/8” 1 5/8” 1 1/8” 1 5/8” 1 5/8”
