Page 44: Unit refrigerant charge
EasiCool™EZE
Precision Air Conditioning
44
EasiCool™ EZE Technical Manual 7588163 V1.1.0_02_2013
Ins
ta
lla
tio
n
Refrigerant Charging Guide
The following information can be used to estimate the refrigerant quantity required in a typical split system installation.
Unit Refrigerant Charge
(kg / Circuit)
The following information can be used to estimate the refrigerant quantity required in a typical split system installation.
The table shows the refrigerant charge / circuit for the indoor and outdoor units.
Indoor Unit
Standard Condenser
Upgraded Condenser
(IR)
kg/Circuit
(OR)
kg/Circuit
(OR)
kg/Circuit
DF6X-EZE
2
C11
2.1
C15
2.1
DF8X-EZE
2
C15
2.1
C20
2.3
DF10X-EZE
2
C15
2.1
C20
2.3
DF13X-EZE
3.2
C20
2.3
C25
3.1
DF15X-EZE
3.2
C25
3.1
C35
6.1
DF17X-EZE
3.2
C35
6.1
C45
6.1
DF22X2-EZE
4.1
C45
6.1
CS50
4.3
DF25X2-EZE
4.1
C45
6.1
CS50
4.3
DF26X-EZE
4.9
C45
6.1
CS50
4.3
DF28X-EZE
4.9
C45
6.1
CS50
4.3
DF31X-EZE
4.9
C45
6.1
CS50
4.3
DF35X-EZE
6.5
CS50
4.3
CS65
8.5
DF40X-EZE
6.5
CS50
4.3
CS65
8.5
DF45X2-EZE
7.9
CS50
4.3
CS65
8.5
DF50X2-EZE
7.7
CS65
8.5
CS80
7.3
DF55X2-EZE
9.4
CS80
7.3
CS105
14.6
DF60X2-EZE
9.4
CS80
7.3
CS105
14.6
Indoor Unit
Standard Condenser
Upgraded Condenser
(IR)
kg/Circuit
(OR)
kg/Circuit
(OR)
kg/Circuit
V6X-EZE
2
C11
2.1
C15
2.1
V8X-EZE
2
C15
2.1
C20
2.3
V10X-EZE
2
C15
2.1
C20
2.3
V13X-EZE
3.2
C20
2.3
C25
3.1
V15X-EZE
3.2
C25
3.1
C35
6.1
V17X-EZE
3.2
C35
6.1
C45
6.1
V22X2-EZE
4.1
C45
6.1
CS50
4.3
V25X2-EZE
4.1
C45
6.1
CS50
4.3
V26X-EZE
4.9
C45
6.1
CS50
4.3
V28X-EZE
4.9
C45
6.1
CS50
4.3
V31X-EZE
4.9
C45
6.1
CS50
4.3
V35X-EZE
6.5
CS50
4.3
CS65
8.5
V40X-EZE
6.5
CS50
4.3
CS65
8.5
V45X2-EZE
7.9
CS50
4.3
CS65
8.5
V50X2-EZE
7.7
CS65
8.5
CS80
7.3
V55X2-EZE
9.4
CS80
7.3
CS105
14.6
V60X2-EZE
9.4
CS80
7.3
CS105
14.6
