Airedale EasiCool 6kW 64kW - Manual (Page 15)

EasiCool™EZE Precision Air Conditioning
System Configuration
Downflow Upflow
X Type WX Type X Type WX Type
EC Forward Curved Direct Drive Fans 6 - 26
● ● ● ●
Airflow Components
AC Forward Curved Direct Drive Fans 6 - 26
○ ○ ○ ○
AC Forward Curved Belt and Pulley Fans 28 - 60
● ● ● ●
AC Larger Fan Motor**
○ ○ ○ ○
2 way Discharge Grille
– – ○ ○
3 Way Discharge Grille
– – ○ ○
Return Air Grille
– – ● ●
G4 Return Door Air Filter
○ ○ ○ ○
High efficiency Filtration with pre-filter G3+F6
○ ○ ○ ○
●
Standard Feature
○
Optional Feature
–
Not Available
**
Model Dependant on selected units with AC fans as standard.
Airflow Components
EC Direct Drive Forward
Curve Fan
15 EasiCool™ EZE Technical Manual 7588163 V1.1.0_02_2013
Introduction
Pleated Disposable Panel Filter
