EasiCool™EZE
Precision Air Conditioning
76
EasiCool™ EZE Technical Manual 7588163 V1.1.0_02_2013
Te
ch
ni
ca
l
X-
Ty
pe
V
Technical Data Upflow Units X Type
Performance Data
Standard Condenser
TC = Total Cooling
SC = Sensible Cooling
(1) All data quoted is gross
Operating Limits
Indoor Air Temperature
+18°C to +28°C
Indoor RH%
+40% to +55%
Outdoor Temperature
-20°C to +41°C
Cooling Capacity (1)
Ambient
Air On
25°C
30°C
35°C
40°C
(DB°C/%RH)
TC (kW)
SC (kW)
TC (kW)
SC (kW)
TC (kW)
SC (kW)
TC (kW)
SC (kW)
V6X-EZE C11
22/50
6.5
5.9
6.3
5.8
6.0
5.7
5.8
5.6
24/45
6.7
6.4
6.5
6.3
6.2
6.2
5.9
5.9
26/40
6.8
6.8
6.6
6.6
6.3
6.3
6.1
6.1
V8X-EZE C15
22/50
9.0
8.0
8.7
7.8
8.4
7.7
8.1
7.5
24/45
9.3
8.6
9.0
8.5
8.6
8.3
8.3
8.1
26/40
9.5
9.4
9.2
9.2
8.9
8.9
8.5
8.5
V10X-EZE C15
22/50
11.4
10.2
11.0
10.0
10.6
9.8
10.2
9.5
24/45
11.7
11.1
11.3
10.8
10.9
10.6
10.5
10.3
26/40
11.8
11.8
11.5
11.5
11.2
11.2
10.8
10.8
V13X-EZE C20
22/50
11.8
10.7
11.4
10.5
10.9
10.3
10.4
10.0
24/45
12.2
11.7
11.7
11.4
11.2
11.2
10.7
10.7
26/40
12.4
12.4
12.0
12.0
11.4
11.4
10.9
10.9
V15X-EZE C25
22/50
16.3
13.7
15.7
13.4
15.0
13.1
14.2
12.8
24/45
16.8
14.9
16.1
14.6
15.4
14.3
14.6
14.0
26/40
17.1
16.2
16.4
15.9
15.7
15.5
15.0
15.0
V17X-EZE C35
22/50
19.4
17.3
18.7
16.9
18.0
16.5
17.2
16.1
24/45
19.9
18.7
19.2
18.3
18.4
17.9
17.6
17.5
26/40
20.2
20.1
19.6
19.6
18.8
18.8
18.0
18.0
V22X2-EZE C45
22/50
24.8
20.3
23.9
19.9
22.9
19.4
21.8
19.0
24/45
25.8
22.1
25.0
21.7
24.0
21.3
23.0
20.8
26/40
26.6
23.9
25.7
23.5
24.7
23.0
23.6
22.5
V25X2-EZE C45
22/50
25.9
22.2
25.0
21.7
24.0
21.3
22.9
20.7
24/45
26.5
24.1
25.7
23.7
24.7
23.2
23.6
22.7
26/40
27.3
26.3
26.4
25.9
25.4
25.3
24.3
24.3
V26X-EZE C45
22/50
28.8
26.0
27.7
25.4
26.5
24.8
25.1
24.0
24/45
29.5
28.1
28.4
27.5
27.2
26.9
25.7
25.7
26/40
30.2
30.2
29.0
29.0
27.8
27.8
26.3
26.3
V26X2-EZE C45
22/50
30.4
26.8
29.3
26.2
28.1
25.6
26.6
24.8
24/45
31.2
29.0
30.1
28.4
28.8
27.7
27.3
26.9
26/40
31.9
31.2
30.7
30.6
29.5
29.5
28.0
28.0
V28X-EZE C45
22/50
29.4
27.8
28.3
27.1
27.0
26.5
25.6
25.6
24/45
30.2
30.1
29.0
29.0
27.8
27.8
26.3
26.3
26/40
30.1
30.1
29.0
29.0
28.0
28.0
27.1
27.1
