EasiCool™EZE
Precision Air Conditioning
DF35X - DF45X
71
EasiCool™ EZE Technical Manual 7588163 V1.1.0_02_2013
Te
ch
nic
al
X-T
yp
e
DF
Technical Data Downflow Units X Type
Electrical Data
Mechanical
(1)
Entering air 24°C/45% RH ambient 35°C.
(2)
Fan Gain / Fan power input based upon fan operating with design airflow at 25Pa ESP, These values may change with different ESP.
(3)
With Standard forward curved fan motors; Machine weight includes a refrigerant charge.
(4)
Backward curved EC fan options quote electrical power. All other options quote shaft power.
(5)
For refrigerant charges, refer to
Unit Refrigerant Charge (kg/Circuit)
.
(6)
Based on air temperature of 15.5°C leaving the evaporator coil.
(7)
Based upon low pressure hot water 82°C inlet / 71°C outlet. Air on 20°C. Refer to
Low Pressure Hot Water
.
Electrical
(1)
Values given for full function units (incl. electric heating, humidification and matched condenser) at 7°C evaporating and 54.4°C condensing with standard
forward curved fan motors, for optional data, please contact Airedale.
(2)
Values given for Cooling only units (incl. Compressor, evaporator fan and matched condenser) at 7°C evaporating and 54.4°C condensing, for optional
data, please contact Airedale.
(3)
Electrical input power relates to the maximum absorbed electrical power. Actual operating fan power input is shown in the mechanical data tables.
DF35X-EZE-0
DF40X-EZE-0
DF45X-EZE-0
Standard Condenser Match
CS50
CS50
CS50
Unit Data Full Function
(1)
Nominal Run Amps
A
65.4
72.0
75.1
Maximum Start Amps
A
191.3
194.1
224.1
Recommended Mains Fuse Size
A
80
80
100
Unit Data Cooling Only
(2)
Nominal Run Amps
A
33.0
39.5
42.6
Maximum Start Amps
A
158.9
161.6
191.6
Recommended Mains Fuse Size
A
40
50
50
Max Mains Incoming Cable Size
mm²
35
35
35
Mains Supply
V
Mains Supply
Control Circuit
VAC
24
24
24
Evaporator Fan - Per Fan
Maximum Electrical Input Power
(3)
kW
1 x 4
1 x 5.5
1 x 5.5
Full Load Amps
A
8.12
10.9
10.9
Locked Rotor Amps
A
60.9
69.8
69.8
Compressor - Per Compressor
Quantity x Motor Size
kW
1 x 11
1 x 11.9
1 x 13.2
Nominal Run Amps
A
19.1
22.9
26
Locked Rotor Amps
A
145
145
175
Type of Start
Direct On Line
Standard Condenser Match - AC Motor - Per Fan
Quantity x Motor Size
kW
2 x 0.6
2 x 0.6
2 x 0.6
Full Load Amps
A
2.62
2.62
2.62
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
3
3
3
Number of Elements
8
8
8
Rating
kW
20
20
20
Curent per Phase
A
32.48
32.48
32.48
Humidifier
Capacity
kg/hr
15
15
15
Rating
kW
11.25
11.25
11.25
Full Load Amps
A
16.24
16.24
16.24
