Instruction Manual CyberScan DO 110
44
9.4 Capturing And Printing Data Into Computer Using Data Acquisition
After matching the Communication Settings between your computer using Data
Acquisition program and the DO 110 meter, you can now capture data into your
computer for analysis and storage purposes.
1. Ensure the 1-meter RS232 communication cable (Refer to Accessories
Section) is connected between the computer and the DO 110 meter’s Com
port. Refer to section 3.4 “Connecting the RS232C Cable” on page 6 for
connection procedure.
2. Switch on the DO 110 meter and run the Data Acquisition software.
3. Click “ENABLE CONNECTION” button.
4. With the DO 110 meter switched on, press the PRINT key to send data to the
computer.
5. You can use MODE key on the meter and change to mg/L or ppm and print
data accordingly.
6. You can also check off the Time Stamp function, so as to print without the
Time and Date information.
7. You can click Clear Readings button to begin another set of measurements, or
click Save Readings to store readings for future retrieval.
9.5 Trouble-shooting Guide
a) Problem: Unable to PRINT
POSSIBLE CAUSES SOLUTIONS
You have not "ENABLE CONNECTION" in
the Data Acquisition program. Click on "ENABLE CONNECTION" in the
Data Acquisition program.
The "Communication Settings" in the Data
Acquisition program is different from
meter's setup. Match the COM port number, baud rate,
parity and stop bits information between the
Data Acquisition program and the meter.
The COM port number in the Data
Acquisition program is wrong. Change the COM port number (1 or 2) in the
Data Acquisition program.
Your computer's COM port setting may be
wrong. Check your computer's hardware settings
(through Windows OS, BIOS, or any other
OS) and refer to computer's manual or
consult with the computer's manufacturer.
You may have used the wrong
communication cable. Make sure you use the RS232C cable
supplied together with the meter (Part No.
EC-CA01M09F09).
Check the RS232C configuration as
described in the meter's instruction manual.
To report any bugs, please e-mail to [email protected]
