Instruction Manual CyberScan DO 110
15
7 PRINT FUNCTION
The DO 110 meter is equipped with an RS232 communication port and a PRINT
(
) key that facilitate the printing of data from the meter to a printer or computer.
7.1 Using DO 110 Meter With Printer or Computer
1. To use the DO 110 directly with a printer, the printer should have either a 9
pin or a 25 pin RS 232C serial port.
2. Communication settings of the printer or computer’s data acquisition
software (CyberComm Portable DAS) MUST match the following
parameters:
a. Baud Rate: 9600
b. Parity Bit: None
c. Stop Bit: One
d. Data Bit: 8
e. Flow Control: None
3. Please refer to your printer’s or computer’s instruction manual for more
information on its communication setup protocol.
4. Use 9-pin cable (Refer to section 13 - LIST OF ACCESSORIES on page
51) to connect the meter to the printer. If the printer has a 25 pin connector,
use the 9 to 25 pin cable or make your own cable taking note of the
connection parameters as described in section 3.4.1 - RS232C
Configuration on page 7.
5. Turn on DO 110 meter and note the following:
a. For printer, ensure it is powered on and paper is loaded.
b. For computer, ensure that Eutech Instruments’ CyberComm
Portable Data Acquisition Software is installed and activated. See
section 9.3 - on page 41.
6. To send data to the printer or computer, press the PRINT key.
