User’s Manual
36
Selecting located at the bottom displays the Calendar Search screen.
Days with recorded video display on the calendar with white numbers. You can
select the days with recorded video by using the arrow buttons on the remote control.
Once you have selected a day, pressing the
button displays the first recorded
image of the selected date on the screen. Once you have selected the date you
want to search, review the surrounding video by using the playback controls located
at the bottom. Refer to the Recording Video – Playing Recorded Video section
of this chapter for information regarding playback controls.
Selecting located at the bottom displays the Search menu.
y Go To: Displays the first or last recorded image, or searches by date and time (see below for
more details).
y Clip-Copy: Copies a video segment and saves it (see below for more details).
y Zoom: Zooms the current playback image.
y Use De-Interlace: Turns the de-interlace filter on (see below for more details).
y Slow Play: Plays video at low speed (x1/2, x1/3, x1/4, x1/6 and x1/8).
Selecting in the top-left corner exits the Record Table Search screen.
Motion Search
Motion Search can be selected from the Search Filter menu while the DVR displays the camera full screen. The Motion
Search screen displays a list of motion events. Use the arrow buttons to highlight the event for which you would like
to see video and press the
button to display the video associated with the selected event in the small search screen.
Selecting Close and pressing the
button will extract the video associated with the Motion event and display the
first image of the event. Pressing the (Play) button on the remote control button will start playing the “event” video
segment. If you want to return to live monitoring, press the MENU button on the remote control and select the
(Exit)
icon at the top of the screen.
You also can narrow your event search by selecting Option… and setting up new search conditions.
