OPERATION
48
OPTIWAVE 5200 C
www.krohne.com
09/2013 - 4002500101 - AD FF OPTIWAVE 5200 R01 en
UNITS_INDEX
Units Index
RW
Device Description units code index for the engineering unit
descriptor for the associated block value.
m
Settings:
m; cm; mm; ft; in; yd
DECIMAL
Decimal
R
The number of digits to the right of the decimal point which
should be used by an interface device in displaying the
specified parameter.
0
SECONDARY_VALUE
SECONDARY_VALUE
SECONDARY_VALUE
SECONDARY_VALUE
electronic temperature
electronic temperature
electronic temperature
electronic temperature
The Electronic temperature.
STATUS
Status
R
Digital transducers, unlike their analog versions, can detect
faults that make the measurement bad or prevent the
actuator from responding. This additional, valuable
information will be passed along with each transmission of a
data value in the form of a status attribute.
-0
VALUE
Value
R
A numerical quantity entered by a user or calculated by the
algorithm.
SECONDARY_VALUE_UNIT
SECONDARY_VALUE_UNIT
SECONDARY_VALUE_UNIT
SECONDARY_VALUE_UNIT
electronic temperature unit
electronic temperature unit
electronic temperature unit
electronic temperature unit
RW
The engineering units to be used with SECONDARY_VALUE
(electronic temperature).
°C
Setting: °C
SENSOR_CAL_DATE
SENSOR_CAL_DATE
SENSOR_CAL_DATE
SENSOR_CAL_DATE
Sensor Calibration Date
Sensor Calibration Date
Sensor Calibration Date
Sensor Calibration Date
R
The date of the last sensor calibration.
-
SENSOR_CAL_LOC
SENSOR_CAL_LOC
SENSOR_CAL_LOC
SENSOR_CAL_LOC
Sensor Calibration Location
Sensor Calibration Location
Sensor Calibration Location
Sensor Calibration Location
R
The last physical location at which the sensor was calibrated.
(ex. Acme Labs)
-
SENSOR_CAL_METHOD
SENSOR_CAL_METHOD
SENSOR_CAL_METHOD
SENSOR_CAL_METHOD
Sensor Calibration method
Sensor Calibration method
Sensor Calibration method
Sensor Calibration method
R
The method of last sensor calibration. It could be one of the
several standard calibration methods defined by ISO or some
other method.
factory trim
standard
calibration
SENSOR_RANGE
SENSOR_RANGE
SENSOR_RANGE
SENSOR_RANGE
Sensor Range
Sensor Range
Sensor Range
Sensor Range
The High and Low range limit values, the engineering units
code and the number of digits to the right of the decimal point
for the sensor.
EU_100
max value
R
The engineering unit value which represents the upper end of
range of the associated block parameter.
EU_0
min value
R
The engineering unit value which represents the lower end of
range of the associated block parameter.
UNITS_INDEX
Units Index
R
Device Description units code index for the engineering unit
descriptor for the associated block value.
DECIMAL
Decimal
R
The number of digits to the right of the decimal point which
should be used by an interface device in displaying the
specified parameter.
2
SENSOR_SN
SENSOR_SN
SENSOR_SN
SENSOR_SN
Sensor Serial Number
Sensor Serial Number
Sensor Serial Number
Sensor Serial Number
R
The sensor serial number.
SENSOR_TYPE
Sensor Type
R
The type of sensor.
Level
SENSOR_CAL_WHO
SENSOR_CAL_WHO
SENSOR_CAL_WHO
SENSOR_CAL_WHO
Sensor Calibration Who
Sensor Calibration Who
Sensor Calibration Who
Sensor Calibration Who
R
The name of the person responsible for the last sensor
calibration.
TANK_HEIGHT
TANK_HEIGHT
TANK_HEIGHT
TANK_HEIGHT
Tank Height
Tank Height
Tank Height
Tank Height
RW
The distance from the tank connecting flange face/thread stop
down to the tank bottom.
Setting:
0…100000 mm
TANK_TYPE
TANK_TYPE
TANK_TYPE
TANK_TYPE
Tank type
Tank type
Tank type
Tank type
RW
The conditions in which the device is used. If the surface of the
product is flat, select "Storage". If the surface of the product is
disturbed, select "Process". If the surface of the product is
agitated with vortexes and foam, select "Agitator".
Setting:
Storage / Process / Agitator
Parameter
Parameter
Parameter
Parameter
DD name
Access
Description and settings
Initial Value
