OPERATION
4
45
OPTIWAVE 5200 C
www.krohne.com 09/2013 - 4002500101 - AD FF OPTIWAVE 5200 R01 en
MIN_AMP_REQ MIN_AMP_REQ MIN_AMP_REQ MIN_AMP_REQ
Minimum amplitude Minimum amplitude Minimum amplitude Minimum amplitude
required required required required
RW No help available. It is necessary to enter a password to
change this parameter (PASSWRD ResourceBlock/Other).
Setting:
0...100
MIN_PEAK_REQ MIN_PEAK_REQ MIN_PEAK_REQ MIN_PEAK_REQ
Minimum peak required Minimum peak required Minimum peak required Minimum peak required
RW No help available. It is necessary to enter a password to
change this parameter (PASSWRD ResourceBlock/Other).
Setting:
10...10000
MIN_PLAUS_WIN MIN_PLAUS_WIN MIN_PLAUS_WIN MIN_PLAUS_WIN RW No help available. It is necessary to enter a password to
change this parameter (PASSWRD ResourceBlock/Other).
Setting:
300 mm...TANK_HEIGHT
MIN_SWEEP_FREQUENCY MIN_SWEEP_FREQUENCY MIN_SWEEP_FREQUENCY MIN_SWEEP_FREQUENCY
Minimum Sweep Frequency Minimum Sweep Frequency Minimum Sweep Frequency Minimum Sweep Frequency
RW Minimum Sweep Frequency. It is necessary to enter a
password to change this parameter (PASSWRD
ResourceBlock/Other).
Setting:
8.6...10.4 GHz
MULT_REFLECTION MULT_REFLECTION MULT_REFLECTION MULT_REFLECTION
Multiple reflection detection Multiple reflection detection Multiple reflection detection Multiple reflection detection
RW Multiple reflections will cause the device to display smaller
readings. Objects in the tank, sharp corners, installation of the
device on a large nozzle or at the centre of a dome roof can
cause multiple reflections. A very calm surface or a tank with
a small convex or flat roof can also cause multiple reflections.
Setting:
Disabled / Enabled
OVERFILL_DETECT OVERFILL_DETECT OVERFILL_DETECT OVERFILL_DETECT
Overfill detection Overfill detection Overfill detection Overfill detection
RW If this function is switched on, the device will monitor the level
even if it is in the blocking distance. The displayed output stays
fixed at the blocking distance. An error is recorded by default.
Setting:
No / Yes
OVERFILL_DETECT_TH OVERFILL_DETECT_TH OVERFILL_DETECT_TH OVERFILL_DETECT_TH
Overfill detection threshold Overfill detection threshold Overfill detection threshold Overfill detection threshold
RW In case that the level has reached the overfill detection
threshold with OVERFILL_DETECT enabled an error message
will warn the user that the tank is overfilling. It is necessary to
enter a password to change this parameter (PASSWRD
ResourceBlock/Other).
Setting:
0...1600000 mm
OVERFILL_ERROR OVERFILL_ERROR OVERFILL_ERROR OVERFILL_ERROR
Overfill Error Overfill Error Overfill Error Overfill Error
RW Overfill Error Alarm. It is necessary to enter a password to
change this parameter (PASSWRD ResourceBlock/Other).
Setting:
Warning / Error
PEAK_LOST PEAK_LOST PEAK_LOST PEAK_LOST
Peak Lost Alarm Peak Lost Alarm Peak Lost Alarm Peak Lost Alarm
RW Peak Lost Alarm. It is necessary to enter a password to
change this parameter (PASSWRD ResourceBlock/Other).
Setting:
Warning / Error
PIPE_DIAMETER PIPE_DIAMETER PIPE_DIAMETER PIPE_DIAMETER
Stilling well diameter Stilling well diameter Stilling well diameter Stilling well diameter
RW The inner diameter of the stilling well. If the device is installed
in a stilling well or has a Wave-Guide antenna, enter the
diameter. The device will use this data if you set
PIPE_ENABLED to "Yes".
Setting:
0.022...999.0
PIPE_ENABLED PIPE_ENABLED PIPE_ENABLED PIPE_ENABLED
Stilling well enable Stilling well enable Stilling well enable Stilling well enable
RW If the device is installed in a stilling well or has a Wave-Guide
antenna, set this parameter to "Yes".
Setting:
No / Yes
Parameter Parameter Parameter Parameter
DD name Access Description and settings Initial Value
