KROHNE OPTIWAVE 5200 FOUNDATION FIELDBUS - Manual (Page 44)

4
OPERATION
44
OPTIWAVE 5200 C
www.krohne.com 09/2013 - 4002500101 - AD FF OPTIWAVE 5200 R01 en
CORRECTION_FACTOR CORRECTION_FACTOR CORRECTION_FACTOR CORRECTION_FACTOR RW No help available. It is necessary to enter a password to
change this parameter (PASSWRD ResourceBlock/Other).
Setting:
0.4...2.0
CORRECTION_OFFSET CORRECTION_OFFSET CORRECTION_OFFSET CORRECTION_OFFSET RW No help available. It is necessary to enter a password to
change this parameter (PASSWRD ResourceBlock/Other).
Setting:
0...2000.0 mm
DISTANCE_PIECE DISTANCE_PIECE DISTANCE_PIECE DISTANCE_PIECE
Distance piece Distance piece Distance piece Distance piece
RW Optional distance piece between the converter and the
process connection.This is for high-temperature applications
more than +150°C / +302°F. The distance piece is 120 mm /
4.7¨ long.
Setting:
0...30000 mm
EMPTY_SPECTRUM EMPTY_SPECTRUM EMPTY_SPECTRUM EMPTY_SPECTRUM
Empty spectrum On/Off Empty spectrum On/Off Empty spectrum On/Off Empty spectrum On/Off
RW This function starts and stops interference signal filter.
Interference signals are the result of fixed and moving
obstacles inside the tank. If you must do a spectrum analysis,
first record an empty spectrum via the device display menu.
Setting:
Off / On
EPSILON_R_PRODUCT EPSILON_R_PRODUCT EPSILON_R_PRODUCT EPSILON_R_PRODUCT
Dielectric constant of the Dielectric constant of the Dielectric constant of the Dielectric constant of the
product product product product
RW The device automatically calculates the level based on the
dielectric constant of the product. If you select "TBF Partial"
or "TBF Full" via parameter MEASURING_MODE, you can
change the value manually to adjust readings.
Setting:
LEVEL_OF_POINT_1_15 LEVEL_OF_POINT_1_15 LEVEL_OF_POINT_1_15 LEVEL_OF_POINT_1_15
Level table Level table Level table Level table
RW Table entries 1-15 containing level values.
LEVEL_OF_POINT_16_30 LEVEL_OF_POINT_16_30 LEVEL_OF_POINT_16_30 LEVEL_OF_POINT_16_30
Level table Level table Level table Level table
RW Table entries 16-30 containing level values.
LIN_TYPE LIN_TYPE LIN_TYPE LIN_TYPE
Linerization Type Linerization Type Linerization Type Linerization Type
R The linerization type used to describe the behavior of the
sensor output.
linear with
input
MEASURING_MODE MEASURING_MODE MEASURING_MODE MEASURING_MODE
Measuring mode Measuring mode Measuring mode Measuring mode
RW The device uses the dielectric constant Er of the tank contents
to monitor level. In direct mode (if the dielectric constant is
high), the level signal is a reflection on the surface of the tank
contents. If the dielectric constant is low, the device uses TBF
mode. The device in TBF mode uses the radar reflection on
the bottom of the tank (the signal goes through the tank
contents). This menu item is set by default to "Direct" for tank
contents with an Er >1.8. If Er is very low (<1.6), use "TBF
Full". If Er is low (Er = 1.5...1.7), use "TBF Partial" mode. "TBF
Partial" is an automatic mode that lets the device make a
selection between "Direct" mode and "TBF" mode. If you use
"TBF Full" or "TBF Partial", enter the dielectric constant via
the parameter PRODUCT_EPSILON_R.
Setting:
Direct / TBF Partial / TBF Full
MAX_AMP_REQ MAX_AMP_REQ MAX_AMP_REQ MAX_AMP_REQ
Maximum amplitude Maximum amplitude Maximum amplitude Maximum amplitude
RW No help available. It is necessary to enter a password to
change this parameter (PASSWRD ResourceBlock/Other).
Setting:
0...100
MAX_SWEEP_FREQUENCY MAX_SWEEP_FREQUENCY MAX_SWEEP_FREQUENCY MAX_SWEEP_FREQUENCY
Maximum Sweep Frequency Maximum Sweep Frequency Maximum Sweep Frequency Maximum Sweep Frequency
RW Maximum Sweep Frequency. It is necessary to enter a
password to change this parameter (PASSWRD
ResourceBlock/Other).
Setting:
8.6...10.4 GHz
Parameter Parameter Parameter Parameter
DD name Access Description and settings Initial Value
