0/2
Part C Special applications, functional checks, service, and order numbers 6/1-9/1
6 Special applications 6/1-6/2
6.1 HHT 010 hand held terminal and RS 232 adapter incl. CONFIG software (options) 6/1
6.2 Stable signal outputs when measuring tube empty 6/2
7 Functional checks 7/1-7/11
7.1 Zero check with IFC 010 / D, signal converter, Fct. 3.03 7/1
7.2 Test of measuring range Q, Fct. 2.01 7/1
7.3 Hardware information and error status, Fct. 2.02 7/2
7.4 Faults and symptoms during start-up and process flow measurement 7/3-7/6
7.5 Test of primary head 7/7
7.6 Test of signal converter 7/8
7.7 Test of signal converter using GS 8A simulator (option) 7/9-7/11
8 Service 8/1-8/6
8.1 Cleaning the signal converter housing 8/1
8.2 Replacement of power fuse(s) 8/1
8.3 Changeover of operating voltage on AC Versions 1, 2 and 3 (not DC Version) 8/2
8.4 Replacement of electronic unit of signal converter 8/2
8.5 Illustrations to Sect. 8.2 to 8.7 8/3
8.6 Turning the display PCB 8/4
8.7 Retrofitting the display unit 8/4
8.8 IFC 080 and SC 80 AS Replacement of electronic unit by IFC 010 8/4
8.9 Illustrations of the PCBs 8/6
9 Order numbers 9/1
Part D Technical data, measuring principle and block diagram 10/1-12/1
10 Technical data 10/1-10/5
10.1 Full-scale range Q
100%
10/1
10.2 Error limits at reference conditions 10/2
10.3 IFC 010 Signal converter 10/3-10/4
10.4 IFC 010 F and ZD dimensions and weights 10/4
10.5 Instrument name plates 10/5
11 Measuring principle and function of the system 11/1
12 Block diagram - signal converter 12/1
Part E Index E1-E2
Printed form to accompany flowmeters returned to Krohne E3
