3 INSTALLATION
Label Level Select /
Input
Explanation
LANGUAGE 3.1 Language selection for the menu texts displayed
3.1.1 ENGLISH The menu texts are displayed in the selected language.
3.1.2 DEUTSCH
3.1.3 FRANCAIS
3.1.4 ITALIANO
3.1.5 ESPANOL
3.1.6 CESKY
3.1.7 POLSKI
3.1.8 NEDERLANDS
3.1.9 DANSK
FUNCTION B1 3.2 INACTIVE The binary switching output B1 has no function.
SWITCHING
POINT
The binary switching point B1 functions as a limit switch depending on
the current flow value.
Configuration of the switching point takes place under Fct. 1.1.1 (FLOW.
VAL B1).
COUNTERLIM. The binary switching point B1 functions as a limit switch depending on
the current counter value.
Configuration of the switching point takes place under Fct. 1.1.1 (ZHL.
WERT B1)
PULSEOUTP. The binary switching point B1 functions as a pulse output depending on
the current flow value.
Pulses can be generated up to a maximum of 10 Hz.
Configuration occurs under Fct. 1.3.1 (pulse duration) and Fct. 1.3.2
pulse/unit).
Note: Note: Note: Note:
Configuration under Fct 3.6 / Fct. 1.3.1 and Fct. 1.3.2 applies to both
pulse outputs. If both B1 and B2 are configured as pulse outputs, both
binary outputs behave in exactly the same way.
CONTACT B1 3.3 NO CONTACT Binary switching output B1 is an NO contact.
NC contact Binary switching output B1 is an NC contact.
FUNCTION B2 3.4 INACTIVE See FUNCTION B1
SWITCHING
POINT
See FUNCTION B1
Configuration of the switching point takes place under Fct. 1.2.1 (FLOW.
VALUE B2).
COUNTERLIM. See FUNCTION B1
Configuration of the switching point takes place under Fct. 1.2.1
(COUNTER. VAL B2)
PULSEOUTP. See FUNCTION B1
Configuration occurs under Fct. 1.3.1 (pulse width) and Fct. 1.3.2
(pulse/unit).
CONTACT B2 3.5 NC contact See CONTACT B1
NO CONTACT See CONTACT B1
