3.4 Technical data
INFORMATION!
Although the PROFIBUS MBP technology supports power supply via the PROFIBUS line the
"signal converter PROFIBUS MBP interface" will operate only if the additional power supply for
the device is connected / available.
For a detailed description please check the signal converter handbook. Refer also to the
PROFIBUS PA user and installation guideline (Version 2.2, February 2003 PNO order no. 2.092).
Hardware
Type PROFIBUS RS485 interface according to IEC 61158-2 with
31.25 kbits/s; voltage mode
Connection Independent of polarity at electrical connection
Base current 10.5 mA
FDE Yes, separate fault disconnection electronics provided (FDE = Fault
Disconnection Electronics)
Fault current 6 mA (fault current = max. continuous current – base current)
Starting current <12 mA
Ex approval Ex ia IIC or Ex ib IIC/IIB, FISCO Device
For detailed information refer to standard product documentation.
Software
GSD GSD file on CD-ROM or from internet site
Device profile PA Profile compact class B, V 3.0
Address range 0…126 (default 126)
0…125 via PROFIBUS service set_slave_add
0…126 via local display
126 via factory_reset = 2712
Local control Local display and operator interface at device
SAPs 2 x MS1 SAPs – acyclic interface to PLC
3 x MS2 SAPs – the number of MS2 Service Access Points is typically
equal to the maximum number of master class 2 tools
Function blocks 1 x TB = Transducer Block: contains the parameters and functions
defined in PA Profile 3.0
1 x PB = Physical Block: contains the parameters defined in PA
Profile 3.0
5 x AI = Analog Input Blocks: contains the parameters defined in PA
Profile 3.0
3 x TOT = Totalizer Function Blocks: contains the parameters defined
in PA Profile 3.0
