KROHNE IFC 100 Converter FOUNDATION FIELDBUS - Manual (Page 28)

4
OPERATION
28
IFC 100
www.krohne.com 02/2012 - 4001702901 - AD IFC 100 FF R01 en
UNITS_INDEX
Units Index
R/W Device Description units code index for the engineering unit
descriptor for the associated block value.
° C
Setting:
K; °C; °F; °R
DECIMAL
Decimal
R The number of digits to the right of the decimal point which
should be used by an interface device in displaying the
specified parameter.
2
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
TYPE_5 TYPE_5 TYPE_5 TYPE_5
Primary Value Type
R The type of measurement represented by the primary value.
For example: mass flow, absolute pressure, differential
temperature.
conductivity
PRIMARY_VALUE_5 PRIMARY_VALUE_5 PRIMARY_VALUE_5 PRIMARY_VALUE_5
conductivity
The measured conductivity value and status available to the
function block.
-
STATUS
Status
R Digital transducers, unlike their analogue versions, can detect
faults that make the measurement bad or prevent the
actuator from responding. This additional, valuable
information will be passed along with each transmission of a
data value in the form of a status attribute.
-
VALUE
Value
R A numerical quantity entered by a user or calculated by the
algorithm.
-
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
RANGE_5 RANGE_5 RANGE_5 RANGE_5
conductivity range
The high and low range limit values, the engineering units
code and the number of digits to the right of the decimal point
to be used to display the "Primary Value".
-
EU_100
max value
R The engineering unit value which represents the upper end of
range of the associated Block Parameter.
100
EU_0
min value
R The engineering unit value which represents the lower end of
range of the associated Block Parameter.
0.0
UNITS_INDEX
Units Index
R/W Device Description units code index for the engineering unit
descriptor for the associated block value.
µ S/cm
Setting:
μS/mm; μS/cm; mS/m; μS/m; S/cm; S/m; MS/m; kS/m
DECIMAL
Decimal
R The number of digits to the right of the decimal point which
should be used by an interface device in displaying the
specified parameter.
0
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
TYPE_6 TYPE_6 TYPE_6 TYPE_6
Primary Value Type
R The type of measurement represented by the primary value.
For example: mass flow, absolute pressure, differential
temperature.
electronic
temperature
PRIMARY_VALUE_6 PRIMARY_VALUE_6 PRIMARY_VALUE_6 PRIMARY_VALUE_6
electronic
temperature
The measured electronic temperature value and status
available to the function block.
-
STATUS
Status
R Digital transducers, unlike their analogue versions, can detect
faults that make the measurement bad or prevent the
actuator from responding. This additional, valuable
information will be passed along with each transmission of a
data value in the form of a status attribute.
-
VALUE
Value
R A numerical quantity entered by a user or calculated by the
algorithm.
-
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
RANGE_6 RANGE_6 RANGE_6 RANGE_6
electronic
temperature range
The high and low range limit values, the engineering units
code and the number of digits to the right of the decimal point
to be used to display the "Primary Value".
-
EU_100
max value
R The engineering unit value which represents the upper end of
range of the associated Block Parameter.
100
EU_0
min value
R The engineering unit value which represents the lower end of
range of the associated Block Parameter.
0.0
Parameter Parameter Parameter Parameter
Subelement Access Description and settings Initial Value
