3.13.3.7 STATUS SUBSYSTEM
This subsystem programs the Series EL status register. The electronic load has two groups of
status registers: Operation and Questionable. Each group consists of three registers: Condition,
Enable, and Event.
3.13.3.8 SYSTEM SUBSYSTEM
This subsystem controls various system functions.
FIGURE 3-3. TREE DIAGRAM OF SCPI COMMANDS USED WITH SERIES EL ELECTRONIC LOAD
LOCK subsystem
LOCK
STATus subsystem
STAT
:CHAN?
:COND?
:ENAB
:ENAB?
[:EVEN]?
:CSUM?
:ENAB
:ENAB?
[:EVEN]?
:OPER
:COND?
:ENAB
:ENAB?
[:EVEN]?
:NTR
:PTR
:QUES
:COND?
:ENAB
:ENAB?
[:EVEN]?
DIAGnostic subsystem
DIAG
:RES
:TREE
:DISP
:SEP
:SEP?
ROOT :
(colon)
[SOUR:]
POW
[:LEV]
[:IMM]
[:AMPL]
[:AMPL?]
:PROT
:PROT?
:STAT 0
:STAT?
:PROT[:LEV]?
RES
[:LEV]
[:IMM]
[:AMPL]
[:AMPL?]
VOLT
[:LEV]
[:IMM]
[:AMPL]
[:AMPL?]
:PROT
[:LEV]
:OVER
STAT 0
STAT?
:OVER?
:UND
STAT 0
STAT?
:UND?
:PROT[:LEV]?
[SOURce:] subsystem
[SOUR:]
INP
:CUT
:TIME
:TIME?
:VOLT
:VOLT?
:PROT
:CLE
:RAMP
:RAMP?
INP?
OUTP
:PROT
:CLE
OUTP?
MEAS
:ALL
:ALL2
:CURR
:POW
:VOLT
COND
[:LEV]
[:IMM]
[:AMPL]
[:AMPL?]
CURR
[:LEV]
[:IMM]
[:AMPL]
[:AMPL?]
:PROT[:LEV]
:STAT 0
:STAT?
:PROT[:LEV]?
SYSTem subsystem
COMM
[:GPIB]:ADDR
[:GPIB]:ADDR?
:ECHO
:ECHO?
:LAN
:IPAD
:IPAD?
:MAC?
:MODE
:MODE?
:SUBN
:SUBN?
DAMP
DAMP?
ERR?
EXT
EXT?
FAN
FAN?
PFM
PFM?
:LIST?
:STAT?
RANG
:CURR
:CURR?
:POW
:POW?
:VOLT
:VOLT?
REPLY
REPLY?
SERN?
SETT?
VERS?
