Appendix
35
A
PPENDIX
Fuse Replacement
1. Take off
the Handle In order to detach the handle from the unit, turn the
handle down 90 degrees, then pull it off sideways.
INPU TS B EFOR E O P ENIN G
TO A VOI D SH O CK, RE MOV E W AR NING AC 220V 5 0/ 60H z
21 VA 17W
2. Take off
the Cover Take off the two metal holdings from the handle joint.
Then take the top screw off from the rear panel.
INPU TS BE FORE OP ENING TO A VOID SH O CK, REM OVE W AR N ING AC 220V 50 / 60H z
21VA 17W
