SFG-1000 Series User Manual
24
Limitation
Note that the output amplitude, including the offset, is
still limited to:
−5 ~ +5V (50Ω load)
−10 ~ +10V (no load)
Therefore excessive offset leads to peak clip as below.
Positive peak
clip (50Ω)
+5V
-5V
Offset
Clipped
Negative peak
clip (50Ω)
+5V
-5V
Offset
Clipped
