Details screen
Pressing the Enter button while an event message is selected displays the
Details screen. The system displays this screen as long as you are pressing the
Enter button or using the Up and Down cursor buttons. The system returns to the
Event Message screen after approximately 20 seconds of inactivity. You can also
toggle between the Event Message and Details screens by pressing and
releasing the Enter button.
(1) Scrolling symbols: The symbols at the right of the screen title line show whether there are
more detail messages before or after the current message. Use the Up and Down cursor
buttons to scroll through the detail messages or devices in the zone. The up or down symbols
disappear when you reach the start or end of the list (or when there are no off-normal
devices).
(2) Device address: The panel (P), card (C), and device number (D) that constitute the complete
device address for the device generating the event message.
(3) Device message lines: If programmed, the device message for the device that generated the
event message. This is usually a location description.
The Details screen provides details about the zone or device that generated the
selected event message. If the selected event message is for a zone, the Details
screen shows which devices in the zone are active.
Example Details screen
DETAILS
P:nn C:nn D:nnn
DEVICE MESSAGE LINE1
DEVICE MESSAGE LINE2
 (1)
(2)
(3)
DETAILS
P:01 C:01 D:001
East Wing Hallway
South Entrance

