12 R-Series Remote Annunciators and Expanders Installation and Operation Guide
Operating the LCD models
Figure 10: Controls and indicators for: RLCD-C, RLCD-CR, RLCD-CF
Figure 11: Controls and indicators for: RLCD, RLCD-R, RLCDF
Controls Enabled
Ack/Silence
Reset
Signal Silence
Drill
Lamp Test
Power
Alarm
Supervisory
Ground Fault
Trouble
(1)
(2)
(3) (4) (5) (6) (7) (8) (9)
(10)
(11) (12) (13) (14) (15)
Controls Enabled
Ack/Silence
Lamp Test
Power
Alarm
Supervisory
Ground Fault
Trouble
(1)
(2)
(3) (4) (5) (9)
(10)
(11) (12) (13) (14) (15)
