R-Series Remote Annunciators and Expanders Installation and Operation Guide 13
Table 6: Controls and indicators for the RLCD, RLCD-R, RLCDF, RLCD-C, RLCD-CR, and
RLCD-CF
No. Item Description
1 LCD display Displays system status, event messages, and event
message details.
2 Up cursor button Scrolls up through the messages in the event message
queue. Scrolls up through characters for password entry.
3 Down cursor button Scrolls down through the messages in the event message
queue. Scrolls down through characters for password entry.
4 Enter button Displays message details for the current message. Enters
the password character selected.
5 Lamp Test LED-button Green LED that indicates the annunciator is energized.
Turns on all LEDs and displays a test pattern on the LCD.
The test runs for ten seconds. The LED next to the button
indicates the lamp test is running.
6 Drill LED-button Turns on all audible and common alarm output devices and,
if configured, all visible devices. Pressing the button again
turns them back off. The LED next to the button indicates the
function is active. Requires a password to operate.
Note: You must press and hold the button for 2 seconds to
initiate a drill.
7 Signal Silence LED-
button Turns off (silences) all active audible and common alarm
output devices and, if configured, all visible devices.
Pressing the button again turns them back on. The LED next
to the button indicates the function is active. Requires a
password or the enable controls key to operate.
8 Reset LED-button Restores the system to the normal state, provided that no
inputs are latched in the active state. The LED next to the
button indicates the reset function is active. Requires a
password or the enable controls key to operate.
9 Ack/Silence LED-button Silences the panel buzzer and acknowledges all current
events. The LED next to the button indicates the function is
active. Requires a password or the enable controls key to
operate.
10 Controls Enabled LED Blue LED that indicates the controls in that group are
enabled at the annunciator. Enabling the controls requires a
password or the enable controls key.
11 Trouble LED Yellow LED that indicates an active trouble state (flashing =
new trouble event, steady = all current trouble events have
been acknowledged).
12 Ground Fault LED Yellow LED that indicates a ground fault somewhere in the
system.
13 Supervisory LED Yellow LED that indicates an active supervisory state
(flashing = new supervisory event, steady = all current
supervisory events have been acknowledged).
