10 R-Series Remote Annunciators and Expanders Installation and Operation Guide
Troubleshooting
When an R-Series annunciator is operating correctly, the Trouble LED follows
the panel’s Trouble LED. Annunciators with LCD displays show the same trouble
messages as the panel. See the topic “Reading LCD displays” on page 18 for
details about message displays.
The following table summarizes symptoms and solutions for common installation
and operation problems.
Table 5: R-Series troubleshooting
Problem Cause
Panel detail display: Annunciator 000
Communication Fault Communication wiring has an open fault
Communication wiring polarity is reversed
Annunciator has no power
Annunciator address DIP switches are set incorrectly
(on the annunciator shown in the panel message)
Annunciator network baud rate DIP switch is set
incorrectly (for normal operation use 9600 baud)
Annunciator bus type DIP switch is set incorrectly
(change S1-7 to the other position)
Annunciator LCD and LEDs are
inoperative Annunciator has no power
Annunciator control switches don’t work Remote key switch is in the “locked” or disabled
position
Password entry may be required (see “Entering a
password“ on page 20)
Lamp test During a lamp test the annunciators with LCDs show
the version of annunciator firmware currently loaded
