RD-64X Operators Manual
Model RD-64X Operators Manual Rev. 0.1 Page 30 of 30
11.1 Spare Parts
Part Number Spare Parts
949-005169-300 XRD Drop-In Assembly for N4X enclosure
500-005169-100 RD-64X PCA for N7 enclosure
360-STP018-024 Power Supply .75A
975-041400-000 RL-4 Output Module
327-000000-000 Programming Magnet
800-003648-000 Mounting Plate for N7 Enclosure
301-58205 ¾” NPT Cord Connector
500-003087-100 Transient Protection Module
500-005156-000 AC/DC Converter Module
897-850800-010 NEMA 7 Aluminum Condulet Base
897-850400-010 NEMA 7 Aluminum Condulet Solid Cover
8522-750 ¾” NPT Plug
960-202200-000 Condensation prevention packet (For condulet and N7 enclosure,
replace annually)
960-798434-000 Condensation prevention packet (For N4X enclosure, replace
annually)
11.2 Revision Log
Revision Date Changes made Approval
0.0 02/10/2012 Initial Release. LU
0.1 04/02/2012 Added wiring diagram for wireless interconnect LU
