RD-64X Operators Manual
Swipe the ENTER marker to initiate the search. The RD-64X will perform an incremental search for
available controllers/remote displays (X40s/RD-64Xs) starting with Modbus™ address 01h. The search
will continue until Modbus™ address 7Fh is reached or until it is terminated by swiping the ENTER
marker which will save the devices found up to that point and proceed to search for available RL4
modules/alarm stations at Modbus™ addresses 80h, 81h, 82h and 83h or until it is terminated by swiping
the ENTER marker which will save the RL4 modules/alarm stations found up to that point and proceed to
search for available RXT-320 transceivers starting with Modbus™ address 01h. The search will continue
until Modbus™ address 8Fh is reached or until it is terminated by swiping the ENTER marker which will
save the RXT-320 transceivers found up to that point. A swipe of the PROG marker at any time while in
search mode will cancel the search and restore the default settings. Any devices found up to that point will
not be saved.
7.3.2 Set # of Channels/RL4s/Alarm Stations
The SET # OF CHANNELS menu allows the user to set the number of active channels (1-64) to be
monitored and to set the number of RL-4 modules/alarm stations (up to 2 each) for Bank1 and Bank2. The
number of active channels should match the number of sensors connected to the controller being
monitored. Upon entering this menu, the LCD will display:
SET # OF CHANNELS/RL4S/ALARM STATIONS:
CHANNELS: ##
RL4 MODULES/ALARM STATIONS
BANK1: # BANK2: #
These values can be changed by swiping the magnet over the markers of the up or down arrows to move
the arrow prompt “→” to the desired location. A swipe over the ENTER marker will select the field
indicated by the arrow prompt “→” and the value can be changed by swiping over the markers of the up or
down arrows. Another swipe over the ENTER marker will save the selected value.
NOTE: The number of activated channels can be less than (but not greater than) the remote
display’s maximum input capacity.
7.3.3 Set # of RXT-320s (Wireless Function Only)
The SET # OF RXT-320S menu is only applicable to RD-64X remote displays that have the wireless
option installed. This menu is used to automatically search for all available RXT-320 transceivers in the
network. Upon entering this menu, the LCD will display:
SETUP RXT-320S:
RXT 320S IN NETWORK: ##
[CONFIGURE]
Swipe the ENTER marker to initiate the search. The RD-64X remote display will perform an incremental
search for available RXT-320’s starting with Modbus™ address 1 (decimal). The search will continue until
Modbus™ address 143 is reached or until it is terminated by swiping the ENTER marker which will save
the RXT-320’s found up to that point. A swipe of the PROG marker while in search mode will cancel the
search and will not save any RXT-320’s found up to that point.
7.3.4 Set RF Silence and RF Sleep (Wireless Function Only)
The SET RF SILENCE AND RF SLEEP menu allows the user to initiate radio silence over the whole
network. Radio silence terminates communication between all the RXT-320 transceivers in the network.
This menu also allows the user to initiate RF sleep for a set amount of time. This sleep function lets the
Model RD-64X Operators Manual Rev. 0.1 Page 16 of 30
