RD-64X Operators Manual
40053 Status 40117 Status
40054 Reading 40118 Reading
Channel 28
40055 Status
Channel 60
40119 Status
40056 Reading 40120 Reading
Channel 29
40057 Status
Channel 61
40121 Status
40058 Reading 40122 Reading
Channel 30
40059 Status
Channel 62
40123 Status
40060 Reading 40124 Reading
Channel 31
40061 Status
Channel 63
40125 Status
40062 Reading 40126 Reading
Channel 32
40063 Status
Channel 64
40127 Status
Reading Register
Current gas reading of the channel
Status Register
High Byte
Bit 7
NOT USED
Bit 6 NOT USED
Bit 5 NOT USED
Bit 4 NOT USED
Bit 3 NOT USED
Bit 2 NOT USED
Bit 1 NOT USED
Bit 0 NOT USED
Low Byte
Bit 7
1-Reading divisor is 100 (bit 6 read as 0) 0-No reading divisor
Bit 6 1-Reading divisor is 10 (bit 7 read as 0) 0-No reading divisor
Bit 5 1-Comm. Error ON 0- Comm. Error OFF
Bit 4 1-Calibration ON 0- Calibration OFF
Bit 3 1-Fault ON 0- Fault OFF
Bit 2 1-Alarm 3 ON 0- Alarm 3 OFF
Bit 1 1-Alarm 2 ON 0- Alarm 2 OFF
Bit 0 1-Alarm 1 ON 0- Alarm 1 OFF
9. Wireless Option (RXT-320)
The Model RD-64X remote display offers a wireless option that is designed to take Modbus™
communication between devices to a wireless platform. This option takes local Modbus™ communication,
and through the use of a wireless network of transceivers, broadcasts this information throughout a wireless
network platform, creating a seamless network of Modbus™ devices that need not be physically connected
in any way.
The wireless function of the RD-64X remote display is made possible by Detcon’s RXT-320 wireless
transceiver. This transceiver transmits signal data such as analog 4-20mA DC or serial Modbus™ and can
support up to 32 devices. It operates at 2.4GHz and conforms to non-licensed radio frequency appliance
usage around the world. Wireless network integrity and security is accomplished using direct sequence
Model RD-64X Operators Manual Rev. 0.1 Page 26 of 30
