RD-64X Operators Manual
any of these conditions (alarm, fault or communication error) occur, the LCD display will cycle through the
channel screens at a faster rate than when in normal operation.
Four LED indicators on the front panel show alarm and fault alarm output status. The LED’s represent
ALM 1 (yellow), ALM 2 (yellow), ALM 3 (red) and FAULT (blue) and are labeled respectively.
7.3 Menu Functions
RD-64X remote display setup is accomplished through the MAIN MENU. The MAIN MENU consists of
17 menu items:
1) AUTO CONFIGURE SYSTEM
2) SET # OF CHANNELS/RL4S/ALARM STATIONS
3) SET # OF RXT-320S
4) SET RF SILENCE AND RF SLEEP
5) SET COMM BAUD RATES
6) SET MODBUS TIMEOUTS
7) SETUP CHANNEL DATA
8) SET CHANNEL RL4/ALARM STATION BANKS
9) SET RELAY FUNCTION
10) FLASHING BLUE LED CODES
11) SET MODBUS ADDRESS
12) INHIBIT & ALARM TEST MODE
13) RF LINK QUALITY AND BATTERY STATUS
14) SYSTEM DIAGNOSTICS
15) DISPLAY SETTINGS
16) TIME AND DATE
17) VIEW TWA & PEAK
The PROG switch is used to enter the menu mode of the unit by swiping a programming magnet over the
corresponding marker “
⊗”. Upon entering the MAIN MENU, the LCD will display:
MAIN MENU
AUTO CONFIGURE SYSTEM
Use the down arrow “v” switch to move to the next menu item or use the up arrow “u” switch to move to
the previous menu item by swiping the programming magnet over the corresponding markers. Swiping the
PROG switch again will return the unit to normal operation. When the appropriate Menu Item is found, the
ENTER switch is used to enter that menu item by swiping the ENTER marker.
NOTE: The RD-64X remote display automatically times out of Main Menu mode and returns
to the Main Display after 15 seconds of inactivity. While in Menu Mode, there are no updates
to gas readings.
NOTE: The LCD has a backlight that will automatically turn off after a user-defined amount
of inactivity. The LCD backlight will turn on automatically as soon as any magnetic switch is
activated. This is a feature designed to save on power.
There are 17 Main Menu items and their functional descriptions are discussed in the following sections.
Model RD-64X Operators Manual Rev. 0.1 Page 14 of 30
