UNIT INITIALIZATION
When powering up the EMO-1005 unit, the following sequence will display system hardware and
software information.
LINE 1 Ram Test .................
or
Ram test .....................
LINE 2 Ram and no Bat Ram and battery
Line one indicates the RAM memory is being tested. Line two indicates whether the RAM memory
battery back-up is installed and operational.
The next display screen appears as follows:
LINE1 CH1=M/L CH2=R/
LINE 2 CH3=P/ CH4=OFF
where,
CH means channel
the channel number is indicated after the CH.
The letter after the "=" means:
M = Channel in question is in Monitoring Mode
P = Channel in question is in PID Mode
R = Channel in question is in Complex Ratio Mode
OFF = Channel is not installed or is not responding
After the "/", an "L" would indicate the Linearizer is active.
A blank would indicate the Linearizer to be OFF.
If the channel card is in the Gun-On Mode, Transparent Mode or Closed Loop Control (CLC)
Mode the channel will initialize as a P in the above screen.
The next screen is the operating screen with the channel information - actual rate/total values and
engineering units.
A sample of the screen if the unit receiving a frequency signal would appears as follows:
LINE 1 01: 500.00 Hz
LINE 2 01: 22245.0 Imp
