Table of Contents
Introduction 2
Using the EMO-1005
4
Unit Installation 5
Screen Manipulation 6
Display Mode Selection 6
Rate Display 7
Total Display 7
Simple Ratio Display 8
Peak Ratio Display 8
Status Display Mode 9
Programming the EMO-1005 10
Rate
Scaling 12
Totalizer Scaling - KFT 13
Limits Programming 15
Rate Limit 16
Total Limit 16
Analog Gain - KFA 17
Offset Analog Out 18
Sample Amount 18
Cutoff Frequency 19
Analog In Gain 19
Channel Mode Selection
20
Monitor Mode 20
PID Operations 21
Transparent PI Controller 21
Limits in PID Operation 22
Initial Kick 23
Auto Hold 23
Manual Hold 23
Software Change 24
Gun-on PI Controller 25
Complex Ratio Mode 25
Closed Loop Control Mode 26
Linearizer
27
Using the Linearizer 27
Programming the Linearizer 28
Serial Port
29
Serial Port Programming 29
Serial Port Connection Wiring 31
Hardware Hints
36
Back Panel Details 37
Troubleshooting
38
Warranty
40
Appendixes
Quick Reference Key Sequences A
Programmable Parameters B
Analog I/O Circuits C
Digital I/O Circuits D
Back Panel Connections E
Jumper Settings F
Power Supply-Jumpers & Fuses G
Panel Cutouts H
Dimensions I
PID Mode External Hookup J
Fiber Optic Flow Control System K
EMO-1005 w/built in PNAO L
