13
Note: This is merely a convenient display function.
The actual units are scaled thru the KFR factor.
Decimal Point Location
In order to change the scaling just enter the number, and change the decimal point location by pressing
the DP key. After having the desired number in the display press the ENT key once.
Engineering Units
Now by pressing the SPC key the unit display can be changed to one of the following engineering
units:
Hz, GPM, li/m, ci/m, cc/m, lb/m, lb/s, lb/h, gr/s, kg/m,
gr/m, mm/s, cm/m, in/m, ft/m, oz/m, Volt, mV, Amp, mA, PSI,
Bar, F, C, RPM, SSU, cSt, cPs.
Press Enter to exit the KFR scaling.
The default value for the KFR is 0000100.0 (Maximum= 65000) The default engineering unit is Hz
(Hertz).
We recommend removing the insignificant decimal numbers often produced by calculator
mathematics. These are mathematically redundant and may offer a misleading level of precision in the
display. We recommend using a maximum of 4 digits, irrespective of the decimal point position.
Example: 60.675 is no good; better: 60.6
2.3456 is no good; better: 2.345
TOTALIZER SCALING - KFT (Display 2)
By answering with a 0 the scaling will be skipped.
By answering with a 1 the following display appears:
CURRENT KFR/UNIT
XXXXXXXX. YYYY
where,
XXXXXXXX. is the current total scaling
YYYY is the selected engineering units
