SERIAL PORT CONNECTION WIRING
The serial port connection is established through the 9 pin D-sub connector on the back panel of the
unit.
The pin termination is as follows:
PIN 1 - No connection
PIN 2 - RX TTL level (EMO receiving)
PIN 3 - TX Inverted RS-422 (EMO transmitting)
PIN 4 - RX Inverted RS-422 (EMO receiving)
PIN 5 - GND for shielding
PIN 6 - TX TTL level (EMO transmitting)
PIN 7 - TX RS-422 (EMO transmitting)
PIN 8 - RX RS-422 (EMO receiving)
PIN 9 - GND signal
PROTOCOL FORMAT
The EMO-1005 protocol format follows OPTOMUX by the OPTO-22 company.
The EMO-1005 is treated as a smart front end and the host communication is always initiated by
the host computer.
The following are basic commands and answers.
Reading a channel with the host computer:
>03K0F3403XXcr
^.............. start of text always the > sign
^^............ channel address number (00 through FF)
^........... read command is K (J is write)
^^^^......address that should be read 0000-FFFF
^^..... how many bytes to be read 00 through 0D
^^...checksum for the string 03K0F3403
^.. carriage return (decimal 13)
Answer back from the channel would look like this:
A03FF89XXcr
^.............. every answer back starts with an A
^^............ low byte (at address 0F34)
^^.......... next byte (at address 0F35)
^^........next byte (at address 0F36)
^^......checksum for the string 03FF89
^^....carriage return
