MX 9000 Process Monitor
Operation and Programming Manual
7
MX 9000 User Manual, Rev. 2.0 7/16/2013
Specifications

Power Requirements: 16 VAC / 18-24 VDC / 200mA

Sensor/Monitor Input Ratings:
o Frequency Input Range: 0.3-4,500 Hz
o High Level Pulse Input: 5V
PEAK
Min., 24V
PEAK
Max.

Sensor Supply Voltage: 15 VDC @ 50mA Max.

Analog Output(s) 4-20 mA: 16-bit isolated loop powered 2-wire output; 9-24 VDC;
max. load impedance = 500 Ohm @ 24V; max. load impedance = 250 Ohm @ 12V; main
output HART enabled (option)

Opto-Isolated Open-Collector Frequency Output (optional): 5-30 VDC, 40 mA Max.
(minimum load impedance required = 600 Ohm @ 24 VDC)

Opto-Isolated Reset Input: 12-24 VDC Input, 3.3Kohm Impedance

Relay Outputs (optional): 2A @ 100VDC, 1A @ 250VAC MAX.

Temperature Ratings: -4 to 140°F (-20 to 60°C) ambient; 185°F (85°C) max.

Enclosure: DIN #43700, panel mount, plastic

Height = 67mm/2.6 inches; height w/ flange 69mm/2.8 inches

Width = 90mm/3.53 inches; width w/ flange = 97mm/3.8 inches

Depth = 132mm/5.2 inches; depth w/ flange = 139mm/5.5 inches

Connection: spring loaded terminal strips

Display update rate: 250 milliseconds (4 times per second)

Analog output update rate: 20 milliseconds (if Gate Time filter off)

AC Power board (optional): 120 / 240 VAC / 0.5A fuse

Analog Input (optional): 4-20 mA, 0-5 VDC, 0-10 VDC

USB connector: Type B
