RATE time base
Use the UP or DOWN buttons to select the time base to use in conjunction with the previously selected
RATE units to define the flow rate unit. The available time units are:
Seconds
Minutes
Hours
Days
When the correct time base is showing, press ENTER to continue.
NOTE: If the rate unit & time base are selected as PUL & Seconds, the RATE screen will show the unit
as Hz, NOT PUL/SEC.
TOTAL units
Use the UP and DOWN buttons to scroll through the available units to scale the TOTAL and GRAND
TOTAL screens.
The available units are:
GAL (US gallons)
LIT (Liters)
CC (Cubic centimeters)
BBL (Barrels)
ML (Milliliters)
M3 (Cubic meters)
OZ (Liquid ounces)
PUL (Pulses)
The Rate and Total units do not have to be the same. Once the desired unit is showing, pressing ENTER
completes the scaling programming for channel A. Repeat the above to program channel B. When
done, you will be at the Analog programming menu.
