MX 9000 Process Monitor
Operation and Programming Manual
25
MX 9000 User Manual, Rev. 2.0 7/16/2013
Analog output scaling
Sub menus
Figure 12: Analog Output Scaling
When entering the Analog programming menu, the first screen asks to select the Analog Source, or what
the analog output value is to represent. There are 7 choices:
RATE A
TOTAL A
Grand Total A
Rate B
TOTAL B
Grand Total B
Fixed Output
Using the UP and DOWN buttons scrolls through the 7 choices that the mA output can represent: a fixed
mA output value, input flow rate A or B, the totalizer value A or B, or the grand totalizer value A or B.
Press
ENTER when desired choice is showing.
Ana log Programming?
NO YES
EXIT Sel ect Analog Source
RATE A
Sel ect Analog Source
TOTAL A
Sel ect Analog Source
Gra nd Tota l A
Sel ect Analog Source
RATE B
Sel ect Analog Source
TOTAL B
Sel ect Analog Source
Gra nd Tota l B
Sel ect Analog Source
Fi xed Output
