MX 9000 Process Monitor
Operation and Programming Manual
41
MX 9000 User Manual, Rev. 2.0 7/16/2013
When the desired batch number is selected using the external Batch Select switch, push the ENTER
pushbutton. The “SET BATCH” screen appears:
where NN is the batch number 1 through 20. Push
SELECT to enter program data for this batch.
DELAY
This variable sets the delay time for Limit 1 relay (high flow solenoid output) relative to the START input.
Typical delays are from 0.00 to 4.00 seconds. This function is used in slow start applications where
Limit 2 relay (low flow solenoid output) is energized immediately at a START input and Limit 1 relay (high
flow solenoid output) is turned on after the DELAY time.
Enter the delay value desired for this batch to delay the Limit 1 relay output activation on start using the
DOWN – UP – SELECT buttons and press ENTER .
BATCH LIMITS
Enter the value desired for this batch to activate the Limit 1 relay output using the
DOWN – UP – SELECT
buttons and press ENTER . In an identical manner set the value for the S2 / Limit 2 relay output (batch
total). Select the desired engineering units for the display and press ENTER .
Continue to program all desired batch presets up to a total of 20. When finished, return the Program /
Run switch to the “RUN” position.
SET BATCH # NN
SET EXIT
S1 (S2)
0000000.00
DELAY
0000000.00 Seconds
