MX 9000 Process Monitor
Operation and Programming Manual
21
MX 9000 User Manual, Rev. 2.0 7/16/2013
The rate A - B screen shows the mathematical difference of the two flows of dual channel units. If the
gate time or linearizer are active those will also be indicated by a LN in the lower left or GT in the lower
right of the display. NOTE: the units of both flows must be the same for this display to work properly.
TOTAL (GrandTotal) A - B screen
The total A - B screen shows the mathematical difference of the two totals of dual channel units. For A
total being greater than B, a plus (+) sign will be displayed. If total B is greater than A, a minus (-) sign
will be displayed. Pushing the
ENTER key will change to the grand total screen. If the gate time or
linearizer are active those will also be indicated by a LN in the lower left or GT in the lower right of the
display. NOTE: the units of both flows must be the same for this display to work properly.
BATCH TOTAL screen
The batch total screen will display the A channel total along with values for S1 and S2 (option board 3 is
required for this feature). The batch function when enabled will turn on relay 1 and 2 when set points 1
and 2 are reached. Hold the
ENTER key in for 5 seconds then you will be taken to the S1 set point
screen. Enter the value to trigger relay 1 using the UP – DOWN – SELECT buttons . The screen will also
turn to blue indicating that set point 1 is being set. Push ENTER to change to the S2 set point screen.
Again enter the value to trigger relay 2 using the UP – DOWN – SELECT buttons. When operating, the
screen will turn blue when set point 1 is reached and relay 1 is activated. When set point 2 is reached
relay 2 is activated and the screen is turned red.
TOTAL A - B
+ 450.00 GPM
BATCH TOTAL
352000.00 GAL
S1 1000.0 S2 2000.0
