MX 9000 Process Monitor
Operation and Programming Manual
16
MX 9000 User Manual, Rev. 2.0 7/16/2013
Run Mode Screens
The run mode screens, as shown below, can be accessed by using the UP and DN buttons.
Info screen shows critical information on MX 9000 model number, serial number and firmware version.
Please have this information available when calling for technical support!
RATE screen A shows active flow rate information in programmed engineering units
RATE screen B shows active flow rate information in programmed engineering units
TOTAL screen A shows totalized volume in programmed engineering units
TOTAL screen B shows totalized volume in programmed engineering units
STATUS screen shows data summary. Flow and total are in un-scaled units of Hertz for flow and Pulses
for total.
RATIO A/B screen displays rate ratio in % between A&B flows
RATIO B/A screen displays rate ratio in % between B&A flows
RT/TO screen A shows both the flow rate and total values in programmed engineering units
RT/TO screen B shows both the flow rate and total values in programmed engineering units
ANALOG OUT screen shows the mA value the MX 9000 is outputting
Limits screen shows status of current relay outputs
Rate A&B screen shows both rates on one screen
Total A&B screen shows both running totals on one screen
Rate A plus B screen shows mathematical total of both rates
Rate A minus B screen shows differential between rate A and rate B
Total / Grand Total A minus B screen shows differential between total A and B
Batch total screen shows current total and relay status
Direction screen shows flow direction when programmed for a dual sensor (quadrature) input
Notice
