Part No. 4801-5124 rev 10-03 Farm Hand Vent Master 24 37
P20 Vent Machine Time Delay Sec. P40 Network Address
P21 Static Pressure Differential P41 Software Version
P22 Tunnel Target Pressure P42 Controller Setup
P25 Tunnel “On” Temp P43 Stage Expansion
P26 Tunnel “Off” Temp P44 Zone Brooder Expansion
P30 Ramping ON/OFF P60 Low Pressure Alarm
P31 High Temp Limit P61 High Pressure Alarm
P32 High Temp Target Pressure P63 Cycle Pressure Alarm
P34 Low Temp Limit P70 Cool Timer Max. %
P35 Low Temp Target Pressure P71 Cool Time Min. %
P1 Sensors P2 Mode P3 Timer
100=Sensor 1 1=Heat 0=Off Timer
020=Sensor 2 2=Cool Stir 1=On Normal Timer
120=Avg. Sen 1&2 3=Cool Neg 2=On Cool Timer
003=Sensor 3 4=Cool Neg Tunnel
103=Avg. Sen 1&3 5=Cool Tunnel
023=Avg. Sen 2&3
123=Avg. Sen 1,2&3
