Powertrak, Inset a – Hired-Hand Farm Hand Series: Vent Master 24 User Manual
Page 21
Part No. 4801-5124 rev 10-03
Farm Hand Vent Master 24
19
14.1 Connecting the Vent Machines to the Vent Master 24
Note: If you are tunneling with this controller, the tunnel inlets must be
connected to “PowerTrak #2”. The vent inlets should be connected to
“PowerTrak #1”
Note: Only 1 PowerTrak can be connected to each PowerTrak outlet. If
additional PowerTraks are needed, the use of relay boxes are necessary
to separate the load.
PowerTrak
AUX
SWITCH
CONTROLLER
AC IN
HOT
NEUT
.
LO
W
E
R
GND.
HOT
OUT
CL
OSE
IN
O
PEN
IN
COM
UPPER
Inset A
PowerTrak #1
Closed
Signal
Com Open Close
Inset A
