Inset a – Hired-Hand Farm Hand Series: Vent Master 24 User Manual
Page 27
Part No. 4801-5124 rev 10-03
Farm Hand Vent Master 24
25
14.7 Connecting the Vent Master 24 to a Series or Parallel Alarm
Note: The internal wiring shows the condition of the alarm relay
during normal conditions (no alarm present). During an alarm
condition, the contact positions will be reversed.
Inset A
Inset A
