System 1000 Power Vent

System 1000 Power Vent

Offset and Differential

Offset and Differential

••

14

14

If the Target Temp is set at 80 degrees, Offset at 4 degrees and
Differential set at 2 degrees, The System will disengage Heat Mode
when building temperature reaches 76 degrees.

Example:

Target Temp

-

Offset

=

Heat Mode Off

80

-

4

=

76

Cool Mode:

If the Target Temp is set at 80 degrees, Offset set at 5 degrees, and
Differential set at 2 degrees, The System will engage the fans when
building temperature reaches 87 degrees.

Example: Target Temp +

Offset

+

Differential

=

Cool Mode On

80

+

5

+

2

=

87

If the Target Temp equals 80 degrees, Offset equals 5 degrees, and
Differential equals 2 degrees, The System will disengage the fans when
building temperature reaches 85 degrees.

Target Temp

+

Offset

=

Cool Mode Off

Example:

80

+

5

=

85
