System 1000 Power Vent

System 1000 Power Vent

Offset and Differential

Offset and Differential

••

13

13

Offset and Differential

Offset and Differential

Offset:

The point above (cool) or below (heat) target temperature where the
stage turns off.

Differential:

The difference in degrees between the temperature a stage comes on
and the temperature the stage goes off.

Examples

Heat Mode:

If the Target Temp is set at 80 degrees, Offset set at 4 degrees, and
Differential set at 2 degrees, The System will engage Heat Mode when
building temperature reaches 74 degrees and the curtains are closed.

Example:

Target

Temp

-

Offset

-

Differential

=

Heat Mode on

80

-

4

-

2

=

74
