Fabric OS Troubleshooting and Diagnostics Guide 35
53-1003141-01
Media-related issues
3
6. Enter the portLogDumpPort portid command where the port ID is the port number; then, view
the device-to-switch communication.
switch:admin> portlogdumpport 8 | more
time task event port cmd args
-------------------------------------------------
Thu Nov 6 16:52:39 2008
16:52:39.066 PORT scn 8 1 00010004,4302000f,02000000
16:52:39.066 PORT scn 8 2 ce3dfab0,d9672800,00000002
16:52:39.066 PORT scn 8 2 ce3dfab0,d9672800,00000080
16:52:39.066 PORT scn 8 5 00000000,00000000,00000002
16:52:39.066 PORT scn 8 1 00010004,4302000f,00000002
16:52:39.066 PORT scn 8 1 00010004,4302000f,02000000
16:52:39.071 PORT ioctl 88010004 1,0 * 4
16:52:42.311 SPEE sn 8 WS 00000000,00000000,00000000
16:52:42.558 SPEE sn 8 NM 00000000,00000000,00000000
16:52:42.558 SPEE sn 8 NF 00000000,00000000,00000000
16:52:42.558 SPEE sn 8 NC 00000001,00000000,00000000
16:52:42.559 LOOP loopscn 8 LIP 8002
16:52:42.559 LOOP loopscn 8 LIP f7f7
16:52:42.572 LOOP loopscn 8 LIM 0
16:52:42.572 PORT Tx3 8 12 22000000,00000000,ffffffff,11010000
16:52:42.572 PORT Rx3 8 12 22000000,00000000,ffffffff,11010000
16:52:42.572 PORT Tx3 8 20 22000000,00000000,ffffffff,11020000
16:52:42.572 PORT Rx3 8 20 22000000,00000000,ffffffff,11020000
16:52:42.572 PORT Tx3 8 20 22000000,00000000,ffffffff,11030000
16:52:42.572 PORT Rx3 8 20 22000000,00000000,ffffffff,11030000
NOTE
Refer to “Port log” on page 96 for overview information about portLogDump.
Media-related issues
This section provides procedures that help pinpoint any media-related issues, such as bad cables
and SFPs, in the fabric. The tests listed in
Table 6 are a combination of structural and functional
tests that can be used to provide an overview of the hardware components and help identify
media-related issues.
• Structural tests perform basic testing of the switch circuit. If a structural test fails, replace the
main board or port blade.
• Functional tests verify the intended operational behavior of the switch by running frames
through ports or bypass circuitry.
TABLE 6 Component test descriptions
Test name Operands Checks
portTest [-ports itemlist] [-iteration count]
[-userdelay time] [-timeout time]
[-pattern pattern] [-patsize size]
[-seed seed] [-listtype porttype] Used to isolate problems to a single replaceable
element and isolate problems to near-end terminal
equipment, far-end terminal equipment, or
transmission line. Diagnostics can be executed every
day or on demand.
spinFab [-nmegs count] [-ports itemlist] [-setfail mode] Tests switch-to-switch ISL cabling and trunk group
operations.
